Prepreg - Fiberglass Woven (7781 E-Glass) - 39.37" Wide x 36" Long x 0.010" Thick - 32% Resin Content w/Black pigment (461 gsm OAW) - 250F Resin

productname image number 0
productname image number 1
productname image number 0
productname image number 1
Full Roll ◾ ~1076 Sqft ◾ 85 Lyds
P/N: 14086-D-FULLROLL
1
$1,029.99
2 - 3
$996.79
4 +
$953.59
Sold by the Linear Yard ◾ Provided In Continuous Length
P/N: 14086-LYD
1
$40.99
2 - 4
$38.79
5 - 9
$36.59
10 +
$35.39
6" x 6" Swatch ◾ Ships Insulated & Frozen
P/N: 14086-SAMPLE
$28.99
Estimated lead time for quantities greater than what is Available Now is expected to be between 2 and 4 weeks.
Efficient, Clean & Easy to Use - Full Rolls Available
Prepreg - Fiberglass Woven (7781 E-Glass) - 39.37" Wide x 36" Long x 0.010" Thick - 32% Resin Content w/Black pigment (461 gsm OAW) - 250F Resin

You may also need

Features & Benefits

You can use our prepregs any number of ways including, but not limited to, autoclave, press, vacuum, and compaction tapes. Since most shops do not have access to an autoclave or heated press, the latter two options are mostly used for smaller operations. This Prepreg material is ideal for use as an isolative inner or outer ply on any project helping to prevent galvanic corrosion.



Prepregs have special policies related to returns and shipping. Please review them here prior to order.

Product Specifications

Common Conversions:

Per Linear Yard (1 lyd =) 1.19 lbs (w/out backing paper)
12.6 ft2
1.17 m2



Per Full Roll (1 =) 85 lyds
100 m
101 lbs (w/out backing paper)
1071 ft2
100 m2



Additional Information

P/N 14086-D-FULLROLL 14086-LYD 14086-SAMPLE
Application
Brand Rock West Composites Rock West Composites Rock West Composites
Clearance
Color
Cure Ply Thickness (CPT) 0.010" 0.010"
Exportable Yes Yes Yes
Fiber Areal Weight 301 GSM 301 GSM
Fiber Type (brand) E-Glass (generic) E-Glass (generic)
Finish
Glass Transition (Tg, DMA)
Height
Major ID
Major OD
Materials Fiberglass Fiberglass Fiberglass
Minor ID
Minor OD
Prepreg Overall Weight 440 GSM 440 GSM
Recommended Cure Temperature 250F (121C) 250F (121C)
Resin Content 32% 32%
Resin System Propreg 250F Propreg 250F
Shelf Life @ 0°F / 40°F / 70°F 6 Mo / 90 Days / 21 Days 6 Mo / 90 Days / 21 Days
Shipping Weight per Unit (includes backing paper and or core)
Tensile Modulus, msi 10.5 10.5
Tensile Strength (ksi) 285.0 285.0
Weight 101.0 0.91 0.023
Width 39.37 39.37
Contact Info
Prepreg - Fiberglass Woven (7781 E-Glass) - 39.37" Wide x 36" Long x 0.010" Thick - 32% Resin Content w/Black pigment (461 gsm OAW) - 250F Resin
P/N 14086-D-GROUP
